2 Channels HLG320 V2 288QB X2 Board DIY Led Grow Panel Light

Basic Information
Place of Origin: Shenzhen China
Brand Name: SolarLux
Certification: CE RoHS
Model Number: Quantum-320
Minimum Order Quantity: 1
Packaging Details: 1pcs/ctn
Delivery Time: 5-7days
Payment Terms: T/T
Supply Ability: 2000PCS/Per Month
Detail Information
Power: 320Watt LED: SAMSUNG LM301H
Driver: INVENTRONICS Dimming: PWM
Spectra: Full Spectrum Material: Aluminum
High Light:

DIY Led Grow Panel Light

,

2 Channels Led Grow Panel Light


Product Description

2 Channels HLG320 V2 288QB X2 Board DIY led grow panel Light led lights for growing plants indoors

2 Channels HLG320 V2 288QB Board DIY led grow panel Light led lights for growing plants indoors

* New Arrival Full Spectrum LED Panel Grow Light

* Optional Top Brand LED Chip Samsung Osram

* Best Coverage for 2'x4'/60cm x 120cm footprint
* Designed to replace HPS/MH 600w

* Optimum Spectrum to simulate sun light

* Fanless design for quiet working space

* Each grow Panel can be adjustable and dimmable.

* Best PAR output with best PPFD to beat any other lights at the same power draw



Quantum LED is a high-performance, full-cycle top-lighting solution for commercial horticulture cultivation, with the power to scale from vegetative growth to higher light intensities in bloom. It was designed for commercial growers to push the envelope with high-PPFD cultivation practices along with sophisticated CO2 supplementation.



2 Channels HLG320 V2 288QB X2 Board DIY Led Grow Panel Light 0

2 Channels HLG320 V2 288QB X2 Board DIY Led Grow Panel Light 1









Model: Quantum-320



LED: SAMSUNG LM301H / OSRAM /SEOUL 395nm



Power: 320Watts



Input Voltage: 100-277Vac



Frequency: 50/60Hz



AC Current: 2.67 A@120Vac  1.33 A@240Vac  1.16A@277Vac



Power Factor: >0.98

Dimming: Manual Dimming / PWM / 0-10V Dimming

Efficacy: 2.56umol/J

Heat Output: 1056BTU/hr

Dimension: 31.5"x12.6"x1.26"

Net Weight: 5.5KGS

Gross Weight: 7.05 KGS

Certificate: CE RoHS


2 Channels HLG320 V2 288QB X2 Board DIY Led Grow Panel Light 2



To create the most advanced spectrum for complete physiological plant growth, we had to challenge every assumption. Not only did this make the spectra better, it made it beautiful. Previously, 660 nm (red) and 450 nm (blue) were the most efficient LED packages, and coincided with peak Chl A and Chl B absorption areas. This led to a negligence of key photoreceptors and pigments outside this range.



Quantum LED is a full-cycle spectrum optimized for rapid growth and complete plant development. Tailored for growing plants from propagation to senescence (germination, clones/cuttings, mothers, vegetative and flowering applications) in indoor environments. With a CRI rating of 85,Quantum LED offers a beautiful work and research environment with vivid colors and greater contrast to study the health of your crop.
